VALVOLE A SFERA ANSI 150 RF CON LEVA DI RITORNO A MOLLA (DEAD MAN), in due pezzi bullonati, disegno ASME B16.34, scartamento ASME B16.10, flange ASME B16,50. Test API 598 (ISO 5208), NACE MR 01-75.
Corpo in ACCIAIO INOX CF8M , trim in inox 316, sedi PTFE, adatta per carburanti fire safe design.
Valvola completa di flangetta superiore ISO 5211. Stelo non eiettabile, disegno fire safe. A richiesta può essere fornita con corpo in Duplex o super Duplex, PN 63 WOG (1000 lbs) con sedi in PTFE.
BALL VALVE ANSI 150 WITH SPRING RETURN HANDLE (DEAD MAN). Two bolted pieces, design ASME B16.34, face to face ASME B16.10, flanges ASME B16,50. Test API 598 (ISO 5208), NACE MR 01-75. Body in stainless steel CF8M trim in stainless steel 316, PTFE seats, suitable for gasoline fire safe design.
The valve is equipped with ISO 5211 top flange. Fire safe design, blow out proof stem. On request can be supplied with body in Duplex or super Duplex.PN 63 WOG (1000 lbs) with PTFE seats.
